Model Name Indoor: HSU-12TurboAqua(FIX)(Pro) Outdoor: HSU-12K(FIX)(Pro) Category: Non Inverter Series: Non Inverter Pro Capacity and Parameters Type: Non Inverter Ton Range (TR): 1.0 Ton Capacity(BTU): 12000 Rated Cooling Capacity (W): 3520 Rated Heating Capacity (W): N/A Rated Power Input Cooling (W): 1210 Rated Power Input Heating (W): N/A Max. Power input Cooling (W): 1400 Max. Power input Heating (W): N/A Energy Efficiency Ratio (EER): 2.93 Seasonal Energy Efficiency Ratio (SEER): N/A Coefficient of Performance (COP): N/A Rated Running Current (A) Cooling: 5.2 Rated Running Current (A) Heating: N/A Max.Running Current (A) Cooling: 6.5 Max.Running Current (A) Heating: N/A Power supply (Ph,V,Hz): 1/230/50HZ Air Circulation (m3/h): 650 Moisture Removal (10-3m3/h): N/A Refrigerant Type: R32 Refrigerant Standard (Kg): 0.600 Refrigerant Pipe Liquid Side Diameter (mm): 6 Refrigerant Pipe Gas Side Diameter (mm): 9 Compressor Type: Rotary Evaporator/Condenser: 7mm 2 Row Grooved Copper Heat Exchangers: Golden Fin Measurements Indoor Indoor Net dimension (mm) W/D/H: 805*200*292 Indoor Package dimension (mm) W/D/H: 874*363*270 Indoor Net weight (kg): 10.0 Indoor Gross weight (kg): 11.5 Indoor Sound power level [dB(A)] Hi/Mid/Low: 41/38/35 Outdoor Outdoor Net dimension (mm) W/D/H: 800*280*553 Outdoor Package dimension (mm) W/D/H: 908*405*625 Outdoor Net weight (kg): 29.5 Outdoor Gross weight (kg): 32.5 Outdoor Sound power level [dB(A)] Hi/Mid/Lo/So: 52 Air Flow Direction Up & Down: Auto Left & Right: Auto User Functions Nano Aqua Sterilization: Yes Dry Mode: Yes Turbo Function: Yes Auto Restart Function: Yes Sleep Mode: Yes Quiet Mode: Yes Timer: Yes Sleep Light On/Off: Yes Automatic Error Detection: Yes Child Lock: Yes

Warranty Compressor (Yrs): 5 Spare Parts and Components (Yrs): 2 Service (Yrs): 2
